2011 BMC Teammachine SLR01 50cm SRAM Force Easton EA70 Mavic Ksyrium ES Selle Italia BB30 road

Sold: $2,011  Buyer: USA

2011 BMC Teammachine SLR01 50cm SRAM Force Easton EA70 Mavic Ksyrium ES Selle Italia BB30 road

Frame and Wheel is auctioning a BMC Teammachine SLR01 on the Frame and Wheel eBay Store. The bicycle was purchased second hand in early 2012. It was unused at the time of purchase. The current owner used it for training. It has about 1,000 miles of use. The bike was never raced. It was never crashed. It has spent much of the past year in storage. The frame set features full carbon construction, BMC Tuned Compliance Concept (TCC) front fork, proprietary BMC quill-style seat post, oversized down tube, oversized chain stays, distinctive “stepped” seat stays, BB30 bottom bracket, tapered top tube, tapered head tube (1 1/8 inch to 1 1/4 inch headset), gloss black and red finish and Swiss design provenance. The bicycle features SRAM Force front and rear derailleurs, SRAM Force cranks set (53T/39T chain rings and 170 mm crank arms), SRAM PG-1070 cassette (12-25), SRAM Force brake set, SRAM Force dual control shifters, Easton EA70 alloy handle bars (42 mm c-c), Easton EA 70 alloy stem (110 mm), Selle Italia SL seat and Mavic Ksyrium ES (Edition Speciale Dixieme Anniversaire Helium) wheels with Continental Ultra Sport tires. The bicycle as shown weighs 14 pounds 13 ounces (6.7 kg). The serial number on the bottom of the bottom bracket reads Y1010SLR 5000269. The serial number on the front fork crown reads YTBCK 104857. The owner is 5 feet 8 inches with an inseam of about 30 inches. Stand over is 76.0 cm. One bottle cage included. Mavic titanium skewers. Pedals not included. There are 160 detailed images of the bicycle at Frame and Wheel’s Flickr page. Please take a look.

Review of condition

The bicycle is in very good condition. It is clean and ready to ride. The shifting is complete in all twenty gears. The brakes activate easily and grip well. There is 5 mm of brake pad. The brake cable housing is not cracked. The hubs spin freely. The spokes are tight and straight. The rims are round. The wheels show no horizontal or vertical variation when placed in the truing stand. There are no dents in the alloy rims. There are no cracks in the hub bodies. There are no cracks in the flanges of the hubs. There is no corrosion on the hubs, the spokes or the skewers. The skewers are straight and complete. The tires hold pressure. There is no road wear on the bottom of the down tube or on the back of the seat tube.  There is no wear on the head tube or seat tube from cable housing rub. There is no cracking, discoloration, bulging, flexing or flaking that raise concerns about the structural integrity of the frame. The rear triangle is in alignment with the centerline of the frame to within 1.5 mm (the width of one penny). The rear derailleur hanger is straight and undamaged. The front derailleur hanger is undamaged and secured firmly. There is no cracking, bulging or flexing that raise concerns about the structural integrity of the front fork. The steer tube does not show any cracks or bulges. The crown race is secured firmly. There is no play in the bottom bracket. The water bottle cage bolts are not stripped or corroded. The handlebar is not bent. The bar tape is mounted securely. There are no rips or abrasions on the seat.  The chain does not read 0.75 or 1.0 on the chain wear tool. Frame and Wheel notes the following. The rear hub spins roughly and will benefit from some expert servicing. The rear tire is worn. The braking surfaces of the wheels show wear. The sides of the seat show wrinkles. There is wear on handlebar center from the stem. There is wear on the seat post from installation and removal.

Frame and Wheel conclusion

Frame and Wheel’s view is that this BMC Teammachine SLR01 will make an excellent choice for the emerging and dedicated road cyclist who wants to upgrade from that second hand aluminum bicycle to a fast, stiff and very light road bike. The bicycle is in very good condition and shows immaterial signs of wear. The new owner will appreciate the smooth double click shifting of the SRAM Force drive train, the light weight and durability of the Mavic Ksyrium ES wheels and the voice of the bike that channels the spirit of Cadel Evans, Tejay van Garderen and George Hincapie. A rare and fine opportunity to obtain a very nice and very lightly used BMC Teammachine SLR01.

Specifications:

Brand: BMC

Model: Team Machine SLR01

Model year: 2011

Size: 50

Color: Gloss black with white lettering red highlights

Frame material: carbon

Frame design: road

Frame serial number: Y1010SLR 5000269

Fork design: standard

Fork material: carbon

Fork model: BMC

Fork serial number: YTBCK 104857

Wheel size: 700c

Frame and Wheel rating: Very good condition

Following measurements are by Frame and Wheel

Total weight with wheels: 14 pounds 13 ounce (6.7 kg)

Total weight without wheels: 9 pounds 5 ounce (4.2 kg)

Front wheel weight with skewer, tire and tube: 2 pounds 3 ounces (1.0 kg)

Rear wheel weight with skewer, tire, tube and cassette: 3 pounds 2 ounces (1.4 kg)

Center of BB to top of seat tube: 50.5 cm

Effective top tube: 52.5 cm (c-c)

Seat post length: 32.0 cm mm (bottom end of seat post to center rails)

Seat post length: 37.0 cm (bottom end of seat post to top of seat)

Stand over height from middle of top tube: 76.0 cm

Wheelbase: 97.5 cm

Following measurements are by BMC

Size: 50

Seat tube: 52.0 cm

Top tube: 53.5 cm

Head tube length: 13.3 cm

Stack: 53.0 cm

Reach: 37.8 cm

Head tube angle: 72.0 degrees

Seat tube angle: 73.5 degrees

Chain stay length: 40.2 cm

Bottom bracket drop: 6.9 cm

Link to BMC Teammachine SLR01 webpage

Front fork

Brand: BMC

Model: TeamMachine SLR01 TCC

Weight: 338 g (weighed by Frame and Wheel)

Length: 37.5 cm

Serial number: YTBCK 104857

Steer tube material: carbon

Steer tube diameter: 1 1/8 inch to 1 1/4 inch

Steer tube length: 21.5 cm (base of crown race to top)

Crown race diameter: 33.0 mm

Crown material: carbon

Drop outs: carbon

Safety tabs: yes

Brake type: caliper

Handlebar

Brand: Easton

Model: EA 70

Material: aluminum alloy

Type: compact / ergonomic

Width (c-c): 42.0 cm

Bar clamp diameter: 31.8 mm

Drop: 130 mm

Reach: 75 mm

Bar tape: Zipp Service Course Black

Headset

Brand: FSA

Steer tube diameter: 1 1/8 inch (28.6.0 mm) to 1 1/4 inch (33.0 mm)

Type: Integrated

Cane Creek Standardized Headset Identification System (SHIS): IS41/28.6 IS47/33.0 (1 1/8 inch upper to 1 1/4 inch lower)

Headset: sealed cartridge bearings FSA carbon top cap, FSA bearing cover

Spacers: 3 x 10 mm 1 x 5 mm carbon

Stem

Brand: Easton

Model:EA 70

Weight: 168 g (Measured by Frame and Wheel)

Material: aluminum alloy

Length: 11.0 cm

Rise: + / - 6 degrees

Steer tube diameter: 1 1/8 inch

Bar clamp diameter: 31.8 mm

Collar stack height: 40.0 mm

Face plate: alloy four bolts

Seat post

Brand: Easton

Model: BMC Tuned Compliance Concept (TCC)

Seat clamp type: double bolt

Seat clamp material: alloy

Head material: carbon

Seat clamp bed dimensions: 45 mm x 39 mm

Weight: 233 g

Offset: zero

Seat post diameter: Easton proprietary

Seat post length: 11.0 cm (bottom end of seat post to minimum insert)

Seat post length: 21.0 cm mm (minimum insert to center rails)

Seat post length: 32.0 cm mm (bottom end of seat post to center rails)

Seat post length: 37.0 cm (bottom end of seat post to top of seat)

Finish: carbon

Seat

Brand: Selle Italia

Model: SL

Model year: 2011

Weight: 214 g (weighed by Frame and Wheel)

Covering: Synthetic

Length: 280 mm

Width: 135 mm

Rails: steel alloy (maganese)

Adjustable rail length: 40 mm

Rail width: 44 mm c-c

Rail diameter: 7 mm x 7 mm

Finish: black

Crank set

Brand: SRAM

Model: Force

Model year: 2011

Chain rings: 53T / 39T double

Bolt circle diameter: 130 mm

Crank arm length: 170 mm

Spider material: carbon

Finish: black

Rear derailleur

Brand: SRAM

Group: Force

Year: 2011

Cage type: Short

Drive train: 10-speed

Finish: chrome

Front derailleur

Brand: SRAM

Group: Force

Year: 2011

Type: Braze-on

Crank set: double

Finish: Chrome

Brakes

Brand: SRAM

Group: Force

Year: 2011

Pads: SRAM by Swisstop for alloy rims

Type: side pull caliper brake

Quick release: yes

Finish: chrome gray

Dual shift levers

Brand: SRAM

Group: Force

Model year: 2011

Hoods: black

Cassette

Brand: SRAM

Model: PG-1070

Year: 2010

Gearing: 12, 13, 14, 15, 16, 17, 19, 21, 23, 25

Bottom bracket

Threading: BB30

Others

Seat collar diameter: proprietary

Drop outs: carbon standard (R) carbon  standard (F)

Rear derailleur hanger: replaceable

Front derailleur hanger: riveted for braze-on

Cabling: external top tube, down tube and chain stay

Chain: SRAM PC-1031

Pedals: not included

Bottle cage (s): Bontrager

Front

Brand: Mavic

Model: Ksyrium ES (Edition Speciale Dixieme Anniversaire Helium)

Model year: 2006

Rim material: aluminum S6000

Rim shell material: aluminum S6000

Series: road

Type: clincher

ETRTO: 622 x 13c

Rim serial number: na

Hub serial number: na

Size: 700c

Front wheel weight with skewer, tire and tube: 2 pounds 3 ounces (1.0 kg)

Spoke count: 18

Spokes: aluminum aero external nipples

Lacing: radial

Hub: Mavic Ksyrium ES

Hub material: carbon shell

Skewer: Mavic titanium

Rim depth: 22.0 mm (at base of spoke measured by Frame and Wheel)

Rim width: 19.0 mm (measured by Frame and Wheel)

Tire: Continental Ultra Sport 700 x 23C

Base tape: na

Over Lock Nut Dimension: 100 mm

Finish: commemorative yellow lettering on red panel

Rear

Brand: Mavic

Model: Ksyrium ES (Edition Speciale Dixieme Anniversaire Helium)

Model year: 2006

Rim material: aluminum S6000

Rim shell material: aluminum S6000

Type: clincher

ETRTO: 622 x 13C

Series: road

Rim serial number: na

Hub serial number: na

Size: 700c

Rear wheel weight with skewer, tire, tube and cassette: 3 pounds 2 ounces (1.4 kg)

Spoke count: 20

Spokes: aluminum aero external nipples

Lacing: 2-cross non drive-side radial drive side

Hub: Mavic Ksyrium ES

Hub material: aluminum

Skewer: Mavic titanium

Rim depth: 25.0 mm (at base of spoke measured by Frame and Wheel)

Rim width: 19.0 mm (measured by Frame and Wheel)

Tire: Continental Ultra Sport 700 x 23C

Base tape: na

Over Lock Nut Dimension: 130 mm

Free hub body: Shimano / SRAM

Finish: commemorative yellow lettering on red panel

2009 Redline Monocog Flight 29er 15 inch hardtail steel single speed disc FSA Ritchey Avid WTB LaserDisc wheel set MTB

Sold: $401  Buyer: USA

2009 Redline Monocog Flight 29er 15 " hardtail steel single speed disc FSA Ritchey Avid WTB LaserDisc wheel

Frame and Wheel is auctioning a Redline Monocog Flight 29er mountain bike on the Frame and Wheel eBay Store. The bicycle was purchased new in 2007. It was used for trail riding. It has had only one owner. It has been in storage. The owner is selling it because he no longer uses it. The frame set features double butted steel construction (Sanko Cromoly), Redline steel front fork, Ritchey Pro seat post, goose neck down tube, slider style rear dropouts, disc brake mounts, English thread bottom bracket, external cup headset (1 1/8 inch), double water bottle cage mounts, multi-speed upgradeability, suspension compatible geometry, pleasing blue finish and Redline cool. The bicycle features FSA Alphadrive cranks (32T with 170 mm crank arms), Surly rear sprocket (19T 3/32 inch), Avid BB5 mechanical disc brakes and levers, Ritchey Pro Rizer handle bars (67 mm c-c), Ritchey Pro stem (90 mm), WTB Rocket seat and WTB LaserDisc 29er wheels with Redline hubs and Maxxis Ignitor 27 mmx 2.1 tires. The bicycle as shown weighs 25 pounds 6 ounces (11.6 kg). The partially obscured serial number on the bottom bracket reads ISB 70...0253. The owner is 5 feet 8 inches with an inseam of 30 inches. Stand over is 76.0 cm. Pedals not included. There are 140 images of the bicycle on the Frame and Wheel Flickr Page. Please have a look.

Review of condition

The bicycle is in good condition. It is clean and ready to ride. The disc brakes activate easily and grip well. The cable housing is not cracked. The cables are not corroded or frayed. The cable stops and eyelets are undamaged and free of obstructions. The hubs spin smoothly and freely. The spokes are tight and straight. The rims are round. There is less than 1.0 mm lateral of lateral variation in the rims when placed in a truing stand. There are no dents or cracks in the rims. There is no corrosion on the spokes. There are no cracks in the hub bodies. There are no cracks in the flanges of the hubs. There is no corrosion on the skewers. The skewers are straight and complete. There are no cracks in the tire side walls. The tires hold pressure. The treads are fresh. The sidewalls are not cracked. The rim stickers are not peeling off. There are no dents, bends or bulges that raise concerns about the structural integrity of the frame. The rear triangle is in alignment with centerline of the frame to within 1.5 millimeters (the width of a penny). There is no corrosion on the frame.

The sliding rear drop outs are secured firmly to the frame and are undamaged. The drop out adjustment bolts are not bent. The rear derailleur hanger is straight and undamaged. There are no dents bends or bulges that raise concerns about the structural integrity of the front fork. The steer tube does not show any cracks or bulges. The crown race is secured firmly. The external cups are mounted securely and are undamaged. The head set is complete. The head set bearings turn smoothly. There is no play in the bottom bracket. There is no corrosion in the water bottle cage bolt holes. The handlebars are not bent. The bar ends are secured firmly. The seat post is not damaged. None of the seat clamp parts are missing. The seat rails are undamaged. The chain does not read 0.75 or 1.0 on the chain wear tool.

Frame and Wheel notes the following. There is a 10 mm x 65 mm abrasion on the left front fork. There is a 10 mm x 40 mm abrasion on the right front fork. There is a 3 mm x 15 mm scratch on the inside surface of the drive side chain stay. There is a 3 mm x 10 mm scratch on the inside surface of the non drive side chain stay. There are scratches on the end of the crank arms. There are light scratches on the bottom of the down tube. There is wear around the drop outs. There is corrosion on the rear drop out adjustment bolts. There is corrosion on the bolts of the rear derailleur hanger. The braking surfaces of the rotors show wear. There is surface corrosion on the rear sprocket. One of the bar end plugs is missing.

Frame and Wheel conclusion

Frame and Wheel’s view is that this Redline Monocog Flight 29er will make a fine choice for the cyclist who wants to ride the trails on 29 inch wheels, but does not seek the complexity of multi speed drive trains, hydraulic braking systems and front and rear shock absorber systems. The bicycle is in good condition and it has many hours of riding remaining in its steel tubes and alloy rims. The new owner will relish the smoothness of the 29 inch wheels, the torque of the single speed drive train, the power of the disc brakes and the voice of the bike that speaks simply of the purity of single speed off road riding. A fine opportunity to join the 29er revolution.

Specifications:

Brand: Redline

Model: Monocog Flight 29er

Model year: 2009

Size: 15 inch

Color: Blue with off-white lettering

Frame material: Sanko Cromoly double butted steel

Frame design: crown-clearing goose-necked down tube, low stand over swept top tube hardtail

Frame serial number: ISB 70...0253

Fork design: Sanko taper leg cromoly fork

Fork material: steel

Fork model: Redline

Fork serial number: na

Wheel size: 29 inch

Frame and Wheel rating: Good condition

Following measurements are by Frame and Wheel

Total weight with wheels: 25 pounds 6 ounces (11.6 kg)

Total weight without wheels: 14 pounds 11 ounces (6.7 kg)

Front wheel weight with skewer, tire and tube: 4 pounds 12 ounces (2.2 kg)

Rear wheel weight with skewer, tire, tube and cassette: 5 pounds 11 ounces (2.6 kg)

Center of BB to top of seat tube: 38.0 cm

Effective top tube: 55.5 cm (c-c)

Seat post length: 40.0 cm mm (bottom end of seat post to center rails)

Stand over height from middle of top tube: 76.0 cm

Bottom bracket height: 29.0 cm

Head tube length: 9.0 cm

Following measurements are by Redline

Size: 15 inch / 38.1 cm

Head tube angle: 71 degrees

Seat tube angle: 72 degrees

Top tube: 22.6 inches / 57.4 cm

Chain stay: 17.5 inches / 44.5 cm

Bottom bracket height: 12.0 inches / 30.4 cm

Fork offset: 1.85 inches / 4.7 cm

Wheel base: 42.5 inches / 108.0 cm

Seat tube: 15.0 inches / 38.1 cm

Head tube: 9.0 cm

Stand over: 29.8 inches / 75.7 cm

2009 Redline Monocog Flight 29er geometry and specifications

Front fork

Brand: Redline

Steer tube material: steel

Steer tube diameter: 1 1/8 inch

Steer tube length: 17.0 cm (base of crown race to top)

Crown material: steel

Finish: blue

Crown race diameter: 30 mm

Drop outs: steel

Safety tabs: yes

Brake type: disc

Handlebar

Brand: Ritchey

Model: Rizer Pro

Finish: Black

Design: Riser

Year: 2009

Material: aluminum 2014

Bend: 9 degrees

Upsweep: 5 degrees

Rise: 35 mm

Width: 67 cm (e-e)

Handlebar clamp: 31.8 mm

Stem

Brand: Ritchey

Model: Pro

Weight: 142 g (Measured by Frame and Wheel)

Material: aluminum alloy

Length: 90 mm

Rise: 6 degrees / 84 degrees

Steer tube diameter: 1 1/8 inch (28.6 mm)

Bar clamp diameter: 31.8 mm

Collar stack height: 40 mm

Face plate: alloy four bolts

Headset

Brand: OEM

Steer tube diameter: 1 1/8 inch (28.6 mm)

Type: external cup

Cane Creek Standardized Headset Identification System (SHIS): EC41/28.6 ∣ EC41/30

Spacers: 1 x 20 mm 1 x 5 mm

Seat post

Brand: Ritchey

Model: Pro

Seat clamp type: double bolt alloy

Seat cradle dimension: 40 mm x 43 mm

Post material: alloy

Head material: alloy

Clamp material: alloy

Weight: 278 g (weighed by Frame and Wheel)

Offset: 15.0 mm

Post diameter: 27.2 mm

Seat post length: 10.0 cm (bottom end of seat post to minimum insert)

Seat post length: 30.0 cm mm (minimum insert to center rails)

Seat post length: 40.0 cm mm (bottom end of seat post to center rails)

Seat post length: 45.0 cm (bottom end of seat post to top of seat)

Finish: Black

Seat

Brand: WTB

Model: Rocket

Model year: 2004

Weight: 279 g (weighed by Frame and Wheel)

Covering: Synthetic

Length: 260 mm

Width: 130 mm

Rails: steel alloy

Adjustable length of rails: 35 mm

Rail width: 45 mm c-c

Rail diameter: 7 mm

Finish: black / silver

Crank set

Brand: FSA

Model: Alphadrive

Model number: CK-715

Crank type: 4-bolt

Year: 2006

Chain ring: 32 single

Bolt circle diameter: 104 mm

Crank arm length: 170 mm

Spider material: alloy

Finish: black

Brakes

Brand: Avid

Group: BB5

Year: 2007

Serial number: 21JUN07T (R) 20JUN10T (F)

Type: mechanical disc brakes

Rotor diameter: 160 mm (F) 160 mm (R) Avid

Brake levers

Brand: Avid

Finish: Chrome

Rear sprocket

Brand: Surly

Gearing: 19T 3/32”

Bottom bracket

Brand: FSA

Model:ISIS 68 mm x 108 mm

Bearing type: sealed cartridge

Threading: English (1.37 x 24 threads per inch)

Shell length: 68 mm

Others

Seat collar diameter: 30.5 mm

Drop outs: sliding steel vertical (R) steel standard (F)

Rear derailleur hanger: replaceable

Front derailleur hanger: clamp-on

Cabling: external

Chain: KMC

Pedals: not included

Bottle cages:

Bar ends: OEM

Front

Brand: WTB

Model: Laser Disc Trail 29er

Model year: 2006

Rim material: alloy

Type: clincher

Size: 29 inch

ERTO: 622 x 21C

ERD: 602

Front wheel weight with tire tube and skewer: 4 pounds 12 ounces (2.2 kg)

Spoke count: 32

Spokes: alloy straight gauge external nipples

Lacing: 3-cross

Hub: Redline disc hubs

Skewer: Redline steel

Rim depth: 17 mm

Rim width: 27 mm (o-o)

Tire: Maxxis Ignitor 29 x 2.10

Over Lock Nut Dimension: 100 mm

Finish: Black

Rear

Brand: WTB

Model: Laser Disc Trail 29er

Model year: 2006

Rim material: alloy

Type: clincher

Size: 29 inch

ERTO: 622 x 21C

ERD: 602

Rear wheel weight with skewer, tire, tube and cassette: 5 pounds 11 ounces (2.6 kg)

Spoke count: 32

Spokes: alloy straight gauge external nipples

Lacing: 3-cross

Hub: Redline disc hubs

Skewer: Redline steel

Rim depth: 17 mm

Rim width: 27 mm (o-o)

Tire: Maxxis Ignitor 29 x 2.10

Over Lock Nut Dimension: 135 mm

Finish: Black

2007 Felt F1C 50cm carbon road Dura-Ace 7900 Mavic Cosmic Elite Reynolds fork Ritchey bars road

Sold: $1,288  Buyer: USA

2007 Felt F1C 50cm carbon road Dura-Ace 7900 Mavic Cosmic Elite Reynolds fork Ritchey bars road

Frame and Wheel is auctioning a Felt F1C bicycle on the Frame and Wheel ebay Store. The owner purchased the bicycle new in 2007. It was used for racing and training for three seasons. The owner switched out the stock components, fork and wheels and replaced them with Dura-Ace 7900 components, a Reynolds Ouzo Pro fork, a FSA SLK crank set and Mavic Cosmic Elite wheels. The bicycle has had only one owner. It has never been crashed. It has been in storage. The owner is selling the bicycle because it is no longer used. The owner is 5 foot 8 inches with an inseam of about 31 inches. The frame set features Reynolds Ouzo Pro carbon front fork, Ritchey Carbon WCS seat post, English thread bottom bracket, integrated head set, semi-matte clear finish, light weight and Felt F1 series design. The bicycle features Shimano Dura-Ace 7900 front and rear derailleurs, FSA SLK crank set (53T/39T chain rings and 170 mm crank arms), Shimano Dura-Ace 7900 brake set, Shimano Dura-Ace 7900 dual control shifters, Ritchey Pro Evocurve alloy handle bars (40 cm c-c), Zipp Service Course SL stem, Devox seat, and Mavic Cosmic Elite wheels with Hutchinson and Vittoria tires. The bicycle as shown weighs 15 pounds 7 ounces (7.0 kg). The serial number on the bottom of the bottom bracket reads F1C/FCMH0173. Stand over is 73.0 cm. Bottle cages included. Pedals not included. There are 240 detailed images of the bicycle at Frame and Wheel’s Flickr page. Please take a look.

Review of condition

The bicycle is in good condition. It is clean and ready to ride. The shifting is complete in all twenty gears. The brakes activate easily and grip well. There is 5 mm of brake pad. The brake cable housing is not cracked. The hubs spin smoothly and freely. The spokes are tight and straight. The rims are round. The rear wheel shows less than 1 mm of horizontal variation when placed in the truing stand. The front wheel shows no lateral variation when placed in a truing stand. There are no dents in the alloy rims. There are no cracks in the hub bodies. There are no cracks in the flanges of the hubs. There is no corrosion on the hubs, the spokes or the skewers. The skewers are straight and complete. The tires hold pressure.

There is no road wear on the bottom of the down tube or on the back of the seat tube. There is no cracking, discoloration, bulging, flexing or flaking that raise concerns about the structural integrity of the frame. The rear triangle is in alignment with the centerline of the frame to within 3.0 mm (the width of two pennies). The rear derailleur hanger is straight and undamaged. The front derailleur hanger is undamaged and secured firmly. There is no cracking, bulging or flexing that raise concerns about the structural integrity of the front fork. The steer tube does not show any cracks or bulges. The crown race is secured firmly. There is no play in the bottom bracket. The water bottle cage bolts are not stripped. The handlebar is not bent. The bar tape is mounted securely. There are no rips or abrasions on the seat.  The chain does not read 0.75 or 1.0 on the chain wear tool.

Frame and Wheel notes the following. There is a 2 mm x 10 mm abrasion on the top edge of the seat stay near the non drive side drop out. There is a 3 mm x 25 mm abrasion on the inside surface of the non drive chain stay from tire rub. There is an 8 mm x 16 mm abrasion on the drive side head tube from cable rub. There is a 20 mm x 30 mm abrasion on the inside surface of the left front fork from tire rub. There are light abrasions on the top of the drive side chain stay from the chain. There is wear around the rear and front drop outs. There is wear on the ends of the crank arms. There is wear on the outside surface of the drive side crank arm. There is wear on the skewer ends.  The barrel adjusters on the down tube show wear. There are scratches on the ends of the brake levers. There is a 3 mm x 3 mm abrasion on the handle bar top. The seat post shows wear from installation and removal. There is a 5 mm x 15 mm abrasion on the wall of the front wheel rim. The labels on the rear wheel show wear. The labels on the tires show wear.

Frame and Wheel conclusion

Frame and Wheel’s view is that this Felt F1C will make an excellent choice for the cyclist who seeks to upgrade to a light and practical full carbon road bike. Although the bicycle shows signs of light wear, it is nevertheless in good condition with many hours of racing and training remaining in its carbon tubes and alloy rims. The new owner will appreciate the smooth shifting and braking of the Dura-Ace 7900 group set, the versatility of the Mavic Cosmic Elite wheels and the voice of the bicycle that speaks plainly and clearly of performance. An excellent opportunity to obtain a fine full carbon road bicycle.

Specifications:

Brand: Felt

Model: F1C

Model year: 2007

Size: 50

Color: semi clear matt black carbon

Frame material: carbon

Frame design: road

Frame serial number: F1C/FCMH0173

Fork design: standard

Fork material: carbon

Fork model: Felt

Fork serial number:

Wheel size: 700c

Frame and Wheel rating: Good condition

Frame and Wheel PAAS charge: $100.00

Following measurements are by Frame and Wheel

Total weight with wheels: 15 pounds 7 ounce (7.0 kg)

Total weight without wheels: 9 pounds 1 ounce (4.1 kg)

Front wheel weight with skewer, tire and tube: 2 pounds 14 ounces (1.3 kg)

Rear wheel weight with skewer, tire, tube and cassette: 3 pounds 8 ounces (1.6 kg)

Center of BB to top of seat tube: 48.0 cm

Effective top tube: 53.0 cm (c-c)

Seat post length from bottom to center rails:  32.5 cm

Seat post length from bottom to top of Devox seat: 37.5 cm

Stand over height from middle of top tube: 73.0 cm

Head tube length: 11.0 cm

Following measurements are by Felt

Size: 50

Head tube angle: 72.0 degrees

Seat tube angle: 76.0

Top tube length (horizontal): 52.5 cm

Top tube length (c-c): 51.5 cm

Head tube length: 11.0 cm

Seat tube length (c-t): 48.0 cm

Seat tube length (c-c): 44.2 cm

Bottom bracket drop: 7.0 cm

Chain stay length: 40.5 cm

Front center: 59.0 cm

Wheelbase: 98.5 cm

Fork rake: 4.5 cm

Stand over height: 73.4 cm

Link to 2007 Felt catalog please see page 12

Front fork

Brand: Reynolds

Model: Ouzo Pro Integrated

Weight: 389 g (weighed by Frame and Wheel)

Length: 38.5 cm

Serial number: not given

Steer tube material: carbon

Steer tube diameter: 1 1/8 inch to 1 1/8 inch

Steer tube length: 17.5 cm (base of crown race to top)

Crown race diameter: 30.0 mm

Crown material: carbon

Drop outs: aluminum

Safety tabs: yes

Brake type: caliper

Handlebar

Brand: Ritchey

Model: Pro Evocurve

Material: aluminum alloy

Width (c-c): 40.0 cm

Bar clamp diameter: 31.8 mm

Drop: 131 mm

Reach: 100 mm

Bar tape: Black

Headset

Brand: Cane Creek

Steer tube diameter: 1 1/8 inch (28.6.0 mm) to 1 1/8 inch

Type: Integrated

Cane Creek Standardized Headset Identification System (SHIS): IS41/28.6  IS41/30.0

Headset: sealed cartridge bearings Reynolds alloy top cap, Cane Creek bearing cover

Spacers: 1 x 10 mm 2 x 5 mm 2 x 2.5 mm carbon

Stem

Brand: Zipp

Model:Service Course SL

Weight: 116 g (Measured by Frame and Wheel)

Material: aluminum alloy

Length: 9.0 cm

Rise: + / - 6 degrees

Steer tube diameter: 1 1/8 inch

Bar clamp diameter: 31.8 mm

Collar stack height: 42.0 mm

Face plate: alloy four bolts

Seat post

Brand: Ritchey

Model: Carbon WCS

Seat clamp type: double bolt

Seat clamp material: alloy

Head material: carbon

Seat clamp bed dimensions: 42 mm x 39 mm

Weight: 184 g

Offset: 25 mm

Seat post diameter: 27.2 mm

Seat post length: 12.0 cm (bottom of seat post to minimum insert)

Seat post length: 25.5 cm mm (minimum insert to center rails)

Seat post length: 32.5 cm mm (bottom to center rails)

Seat post length: 37.5 cm (bottom of seat post to top of seat)

Finish: carbon

Seat

Brand: Felt / Devox

Model year: 2007

Weight: 165 g (weighed by Frame and Wheel)

Covering: Synthetic

Length: 280 mm

Width: 135 mm

Rails: carbon

Adjustable rail length: 55 mm

Rail width: 42 mm c-c

Rail diameter: 7 mm x 9 mm

Finish: black

Crank set

Brand: FSA

Model: SLK

Chain rings: 53T / 39T double

Bolt circle diameter: 130 mm

Crank arm length: 170 mm

Spider material: carbon

Finish: black

Rear derailleur

Brand: Shimano

Group: Dura-Ace

Model: RD-7900

Year: 2009

Cage type: Short

Drive train: 10-speed

Finish: chrome

Front derailleur

Brand: Shimano

Group: Dura-Ace

Model: FD-7900

Year: 2009

Type: Braze-on

Crank set: double

Finish: Chrome

Brakes

Brand: Shimano

Group: Dura-Ace

Model: BR-7900

Year: 200H

Pads: Shimano for alloy rims

Type: side pull caliper brake

Quick release: yes

Finish: chrome

Dual shift levers

Brand: Shimano

Group: Dura-Ace

Model: ST-7900

Hoods: black

Cassette

Brand: Shimano

Group: Dura-Ace

Model: CS-7900

Year: 2009

Gearing: 11, 12, 13, 14, 15, 17, 19, 21, 23, 25

Bottom bracket

Brand: FSA

Model: MegaExo

Threading: English

Others

Seat collar diameter: 30.6 mm

Drop outs: alloy standard (R) alloy standard (F)

Rear derailleur hanger: replaceable

Front derailleur hanger: riveted for braze-on

Cabling: external top tube and down tube; external on chain stay

Chain: SRAM

Pedals: not included

Bottle cages: Specialized

Front

Brand: Mavic

Model: Cosmic Elite

Model year: 2009 estimated

Rim material: aluminum S6000

Rim shell material: aluminum S6000

Series: road

Type: clincher

ETRTO: 622 x 13c

Rim serial number: S80665260

Hub serial number: na

Size: 700c

Front wheel weight with skewer, tire and tube: 2 pounds 14 ounces (1.3 kg)

Spoke count: 20

Spokes: steel aero external nipples

Lacing: radial

Hub: Mavic Cosmic Elite

Hub material: aluminum

Skewer: Mavic

Rim depth: 30.0 mm (measured by Frame and Wheel)

Rim width: 19.0 mm (measured by Frame and Wheel)

Tire: Hutchinson Fusion 2 Ultra 700 x 23C

Base tape: na

Over Lock Nut Dimension: 100 mm

Finish: yellow lettering on black

Rear

Brand: Mavic

Model: Cosmic Elite

Model year: 2009 estimated

Rim material: aluminum S6000

Rim shell material: aluminum S6000

Type: clincher

ETRTO: 622 x 13C

Series: road

Rim serial number: S80665228

Hub serial number: na

Size: 700c

Rear wheel weight with skewer, tire, tube and cassette: 3 pounds 8 ounces (1.6 kg)

Spoke count: 20

Spokes: steel aero external nipples

Lacing: 2-cross drive-side radial non drive side

Hub: Mavic Cosmic Elite

Hub material: aluminum

Skewer: Mavic

Rim depth: 30.0 mm (measured by Frame and Wheel)

Rim width: 19.0 mm (measured by Frame and Wheel)

Tire: Vittoria Diamante 700 x 23C

Base tape: plastic

Over Lock Nut Dimension: 130 mm

Free hub body: Shimano / SRAM

Finish: yellow lettering on black
